Overview
The Hoshizaki UR60B-D2 is a high-performance, ENERGY STAR® qualified undercounter refrigerator designed for commercial kitchens that demand flexibility, durability, and efficiency. With a combination of one solid door and two heavy-duty drawers, this unit offers versatile cold storage in a compact footprint, ideal for tight spaces and high-volume operations.
Key Features
-
NSF-7 Certified: Maintains food-safe temperatures in ambient conditions up to 100°F.
-
ENERGY STAR® Certified: Low energy consumption at just 1.75 kWh/day.
-
Flexible Storage: One door with adjustable shelf and two drawers for full- and quarter-size pans.
-
Heavy-Duty Drawers: Stainless steel construction with acetal rollers, 175 lb. load capacity, and 300,000-cycle life testing.
-
Front Breathing Design: Allows for zero-clearance installation.
-
Magnetic Drawer Gaskets: Snap-in design for easy cleaning and maintenance.
-
E-coated Evaporator Coil: Corrosion-resistant for extended system life.
-
Hot Gas Condensate Removal: Efficient and maintenance-free.
Construction & Durability
-
Exterior: Stainless steel top, front, and sides; coated steel back and bottom.
-
Interior: Stainless steel back, sides, and floor with ABS top.
-
Insulation: 2” CFC-free foamed-in-place polyurethane.
-
Casters: 4” polyolefin stem casters (two with brakes) standard.
-
Handles: Flush-mount extruded aluminum for durability and ease of use.
Mobility & Installation
-
Dimensions: 60” W x 30” D x 33.75” H (with 4” casters)
-
Interior Capacity: 15.1 ft³ (AHAM)
-
Door Opening: 25.5” W x 23” H
-
Depth with Door Open: 58.5”
-
Depth with Drawer Open: 52”
-
Crated Weight: 292 lbs.
-
Crated Dimensions: 62.5” L x 34” W x 36.5” H
-
Electrical Specs:
- Voltage: 115V / 60Hz / 1Ph
- Plug: NEMA 5-15P
- Amperage: 3.0A
- Compressor: 1/5 HP, 798 BTU/hr
- Refrigerant: R290 (2.3 oz)
Certifications & Warranty
-
Certifications: NSF-7, UL, ENERGY STAR®, ETL Sanitation
-
Warranty: 7-Year warranty on compressor, parts, and labor (U.S., Canada, Puerto Rico, and U.S. Territories)
Optional Accessories
- 2.25” or 6” Casters
- Stainless Steel Back Panel
- Drawer Divider Bars (e.g., HS-5433)
- Stainless Steel Shelves
- Overshelves
- Foot Pedal (Right or Left Mount)
Why Choose Hoshizaki?
Hoshizaki is a global leader in commercial refrigeration, known for its commitment to innovation, energy efficiency, and long-lasting performance. The UR60B-D2 is part of the Steelheart® Series, engineered to meet the rigorous demands of professional kitchens. With its robust construction, flexible storage, and energy-saving design, it’s the perfect solution for chefs who need reliable refrigeration in a compact footprint.
Documentation
Spec Sheet
Instruction Manual
Parts Manual
Service Manual
Warranty Statement
Product Brochure
