Hoshizaki KMD-355MAJ Modular Crescent Cuber – Air-Cooled, 395 lbs/24 hrs
Overview
The Hoshizaki KMD-355MAJ is a low-profile, air-cooled modular ice maker designed for beverage dispensers and commercial applications where space and reliability matter. Producing up to 395 lbs. of individual crescent cubes per day, this unit combines energy efficiency, easy maintenance, and superior durability. Ideal for restaurants, bars, and self-service beverage stations, it ensures consistent ice supply with minimal downtime.
Key Features
- High Ice Production: Up to 395 lbs. of crescent ice per 24 hours (at 70°F air / 50°F water)
- Optimized for Beverage Dispensers: Perfect fit for fountain drink systems
- CycleSaver™ Design: Reduces energy consumption while maximizing output
- EverCheck™ Alert System: Self-diagnostic feature for easy troubleshooting
- Factory-Installed Ultrasonic Bin Control: Adjustable for precise ice levels
- CleanAssist™ Technology: Simplifies cleaning with a one-hour process
- H-GUARD Plus Antimicrobial Protection: Enhances food safety
- Removable Air Filters: Easy maintenance for air-cooled models
Construction & Durability
- Stainless Steel Double-Sided Evaporator: Ensures consistent ice quality and long service life
- Durable Exterior: Corrosion-resistant stainless steel panels
- Snap-Fit Components: Simplifies cleaning and servicing
- Compact Design: Low-profile build for tight spaces
Mobility & Installation
- Dimensions: 30" W x 24" D x 22" H
- Shipping Dimensions: 33.75" L x 33.25" W x 28" H (18.18 ft³)
- Weight: 159 lbs. (net) / 179 lbs. (shipping)
- Electrical: 115V/60/1, 15A minimum circuit
- Heat Rejection: 5,100 BTU/hr
- Refrigerant: R-404A (Charge: 1 lb. 9.6 oz.)
- Operating Limits: Ambient 45°F–100°F, Water 45°F–90°F, Water Pressure 10–113 PSIG
- Clearance: 6" at rear, sides, and top for proper air circulation
-
Plumbing:
- Icemaker Water Supply: 1/2" FPT (min. 1/4" ID tubing)
- Icemaker Drain: 3/4" FPT (min. 3/4" ID pipe)
- Compatible Bins & Dispensers: B-500SF, BD-500SF, B-700SF, B-800SF, B-900SF, B-1150SS, DB-130H, DB-200H (Top kit may be required)
Certifications & Warranty
- Certifications: NSF, UL, AHRI, ENERGY STAR®
-
Warranty:
- 3-Year Parts & Labor on entire machine
- 5-Year Parts & Labor on evaporator
- 5-Year Parts on compressor
Optional Accessories
- Top Kits: HS-2148 (DB Top Kit)
- Water Filtration: H9320-51 Single Water Filter Kit, HS-5283 EcO Ice Filter
- Remote Monitoring: HS-5562
- Side-Breathing Kit: HS-5734
Why Choose Hoshizaki?
Hoshizaki is a global leader in commercial ice-making solutions, known for innovation, energy efficiency, and reliability. With features like CycleSaver™, EverCheck™, and CleanAssist™, the KMD-355MAJ delivers consistent performance, reduces operating costs, and ensures food safety. Backed by industry-leading warranties and support, Hoshizaki products are built to last.
